Description
Technical Specifications
| provided equipment |
CD with software
Documentation CD Smart UPS signalling RS-232 cable User manual Warranty card |
|---|
| cable length |
1.83?m
|
|
|---|---|---|
| colour |
Black
|
|
| depth |
48?cm
|
|
| height |
32.7?cm
|
|
| net weight |
22.5?kg
|
|
| width |
16.6?cm
|
| network frequency |
47…63 Hz
50/60 Hz +/- 3 Hz auto-sensing |
|
|---|---|---|
| plug standard |
IEC 60320 C20
|
|
| input voltage limits |
131…268 V adjustable
180…280 V |
|
| inputvolt_other |
220 V
240 V |
|
| switching current capacity |
16?A
|
|
| input voltage |
230 V
|
| rated power in W |
1600?W
|
|
|---|---|---|
| Maximum configurable power in W |
1600?W
|
|
| harmonic distortion |
Less than 3 %
|
|
| output frequency |
50/60 Hz +/- 3 Hz sync to mains
50/60 Hz +/- 1 Hz unsynchronised |
|
| outputvolt_other |
220 V
240 V |
|
| crest factor |
3 : 1
|
|
| UPS type |
Double conversion online
|
|
| Wave type |
Sine wave
|
|
| nb of power socket outlets |
6 IEC 60320 C13
|
|
| output harmonic distortion |
< 3% linear load
|
|
| bypass type |
Built-in bypass
|
|
| output voltage |
230 V
|
| product certifications |
CE
|
|
|---|---|---|
| standards |
EN/IEC 60950-1
EN/IEC 62040-1 EN/IEC 62040-2 |
|
| marking |
CE Mark
|
| ambient air temperature for operation |
0?40??C
|
|
|---|---|---|
| relative humidity |
0?95?%
|
|
| operating altitude |
0…10000 ft
|
|
| ambient air temperature for storage |
-20?50??C
|
|
| storage altitude |
0.00?15240.00?m
|
|
| acoustic level |
45 dBA
|
| battery type |
Lead-acid battery
|
|
|---|---|---|
| number of battery filled slots |
1
|
|
| number of battery free slots |
0
|
|
| Battery recharge time |
4.5?h
|
|
| additional information |
Configurable for 220 : 230 or 240 nominal output voltage
|
|
| liquid value |
0
|
|
| battery voltage |
48 V
|
| free slots |
1
|
|
|---|---|---|
| control panel |
LED status display with load and battery bar-graphs and on line : on battery : replace battery : overload and bypass indicators
|
|
| alarm |
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
|
|
| Emergency power off |
Yes
|
| Surge energy rate |
420?J
|
|
|---|---|---|
| noise suppression |
Full time multi-pole noise filtering : 5% of IEEE surge let-through : zero clamping response time: instantaneous
|
|
| Data line protection |
RJ45 modem/fax protection (four wire dual line)
|
| Package 1 Weight |
25.5?kg
|
|
|---|---|---|
| Package 1 Height |
45.3?cm
|
|
| Package 1 width |
27.3?cm
|
|
| Package 1 Length |
61.1?cm
|
|
| Number of Units in Package 3 |
12
|
|
| Package 3 Weight |
20?kg
|
|
| Package 3 Height |
11.51?cm
|
|
| Package 3 width |
92.51?cm
|
|
| Package 3 Length |
122.5?cm
|
|
| Pallet unit layers |
6
|
|
| Pallet layers |
2
|
| EU RoHS Directive |
Compliant
EU RoHS Declaration |
|
|---|---|---|
| WEEE |
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
|
|
| Optimized Energy Efficiency |
Energy efficient product
|
| Warranty |
2 years repair or replace
|
|---|
