APC Smart-UPS RC 1000VA 230V
APC 1000VA UPS price in Pakistan – Genuine APC UPS available at The Xpert Services, Lahore.
- Model: APC Smart-UPS RC 1000VA 230V
- Pure sine wave output – safe for sensitive devices
- LCD display & automatic voltage regulation (AVR)
- Official warranty included
⚠️ Price Notice: Prices are updated on a daily basis due to market fluctuations. Please confirm the final price before placing your order. Call or WhatsApp us for the latest price.
Description
Output
Max Configurable Power (Watts)
800 Watts / 1.0kVA
Output Voltage Note
Configurable for 220 : 230 or 240 nominal output voltage
Output Voltage Distortion
Less than 3%
Output Frequency (sync to mains)
50/60Hz +/- 3 Hz
Output Frequency (not synced)
50/60 Hz +/-1 Hz
Other Output Voltages
220, 240
Topology
Double Conversion Online
Waveform type
Sine wave
Output Voltage THD
< 3% linear load
Bypass
Built-in Bypass
Input
Input frequency
50/60 Hz
Input voltage range for main operations
160 – 280V
Input voltage adjustable range for mains operation
100 – 280V
Number of Power Cords
2
Other Input Voltages
220, 240
Batteries & Runtime
Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Included Battery Modules
1
Typical recharge time
3hour(s)
Nominal Battery Voltage
36V
Expected Battery Life (years)
3 – 5
Battery Volt-Amp-Hour Capacity
216
Runtime
Efficiency
Communications & Management
Interface Port(s)
DB-9 RS-232, SmartSlot
Control panel
Multi-function LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Emergency Power Off (EPO)
Yes
Available SmartSlot? Interface Quantity
1
Surge Protection and Filtering
Surge energy rating
600 Joules
Data Line Protection
R J- 45 Modem/Fax protection (four wire dual line)
Filtering
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Physical
Maximum Height
230MM, 23.0CM
Maximum Width
145MM, 14.5CM
Maximum Depth
397MM, 39.7CM
Net Weight
9.2KG
Shipping weight
12.4KG
Shipping Height
230MM, 23.0CM
Shipping Width
325MM, 32.5CM
Shipping Depth
475MM, 47.5CM
Color
Charcoal
Environmental
Operating Temperature
0 – 40 ?C
Operating Relative Humidity
0 – 95 %
Storage Temperature
-20 – 50 ?C
Storage Relative Humidity
0 – 95 %
Audible noise at 1 meter from surface of unit
50.0dBA
Conformance
Approvals
EN 60950, EN/IEC 60950-1, EN/IEC 62040-1, EN/IEC 62040-2
Standard warranty
2 years repair or replace
Sustainable Offer Status
RoHS
Compliant
REACH
REACH: Contains No SVHCs
Additional information
| Weight | 16.62 lbs |
|---|---|
| Dimensions | 55.6 × 28.8 × 38.4 in |
