Description

Technical Specifications

• Image Sensor: 1/4″ 1MP Progressive scan CMOS
• Minimum Illumination: 0. 1Lux/F2.0(Color), 0Lux/F2.0(IR on)
• Effective Pixels: 1280(H) x 720(V)
• Shutter Speed: Auto/Manual, 1/3(4)~1/100000s
• White Balance: Auto/Manual
• Lens: 3.6mm fixed lens (2.8mm optional)
• AGC Control: Auto/Manual
• Video Compression: H.264 / MJPEG
• S/N Ratio: More than 50dB
• Back Light Comp: .BLC/ HLC/ DWDR
• Video Streaming: Main Stream: 720P(1 ~ 25/30fps), Extra Stream: D1/CIF(1 ~ 25/30fps)
• Resolution: 720P(1280×720)/ D1(704×576/704×480) /CIF(352×288/352×240)
• Protocol: HTTP;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;DHCP;DNS;DDNS; IPv4/v6;QoS; UPnP; NTP, ONVIF, CGI
• User Account: 20 Users
• Smart Phone: iPhone, iPad, Android Phone
• IR: IR Range of 30 Mtr.
• Operating Temperature: -30°C~+60°C , Less than 95%RH
• Power Source: DC12V, PoE (802.3af)
• Power Consumption: < 5 W(IR on)
• Weatherproof Standard: IP67
• Dimension: Φ70mm×165mm
• Weight: 0.38Kg(with package 0.44 Kg)
