BR1200GI APC Power-Saving Back-UPS Pro 1200, 230V
APC UPS price in Pakistan – Genuine APC UPS available at The Xpert Services, Lahore.
- Model: BR1200GI APC Power-Saving Back-UPS Pro 1200, 230V
- Pure sine wave output – safe for sensitive devices
- LCD display & automatic voltage regulation (AVR)
- Official warranty included
⚠️ Price Notice: Prices are updated on a daily basis due to market fluctuations. Please confirm the final price before placing your order. Call or WhatsApp us for the latest price.
Description
Output
Max Configurable Power (Watts)
720Watts /?1.2kVA
Output Frequency (sync to mains)
50 Hz, 60 Hz
Output Frequency (not synced)
60Hz +/- 0.1% for 60Hz nominal, 50Hz +/- 0.1% for 50Hz nominal
Load Crest Factor
3 : 1
Topology
Line Interactive
Waveform type
Stepped approximation to a sinewave
Transfer Time
10ms typical : 12ms maximum
Input
Input frequency
50/60 Hz +/- 3 Hz (auto sensing)
Input voltage range for main operations
176 – 294V
Input voltage adjustable range for mains operation
156 – 300V
Batteries & Runtime
Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time
8hour(s)
Replacement Battery
Expected Battery Life (years)
3 – 5
RBC Quantity
1
Battery Volt-Amp-Hour Capacity
187
Runtime
Efficiency
Communications & Management
Interface Port(s)
Optional Simple Signalling RS232 cable, USB
Control panel
Multi-function LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Surge energy rating
441Joules
Data Line Protection
Analog phone line for phone/fax/modem/DSL (RJ-11 connector), Network line – 10/100/1000 Base-T Ethernet (RJ-45 connector)
Filtering
Full time multi-pole noise filtering :10% of IEEE surge let-thgouh : zero clamping response time: instantaneous
Physical
Maximum Height
301 MM, 30.1 CM
Maximum Width
112 MM, 11.2 CM
Maximum Depth
380 MM, 38.0 CM
Net Weight
11.6 KG
Shipping weight
13.2 KG
Shipping Height
387 MM, 38.7 CM
Shipping Width
238 MM, 23.8 CM
Shipping Depth
488 MM, 48.8 CM
Color
Black
Master Carton Units
1.0
Units per Pallet
24.0
SCC Codes
1073130426875 5
Environmental
Operating Temperature
0 – 40 ?C
Operating Relative Humidity
0 – 95 %
Operating Elevation
0-9000 meters
Storage Temperature
-15 – 45 ?C
Storage Relative Humidity
0 – 95 %
Storage Elevation
0-15000 meters
Audible noise at 1 meter from surface of unit
45.0 dB A
Conformance
Approvals
A-tick, C-tick, CE, GOST, GS Mark, Telepermit, TUV
Equipment protection policy
Lifetime : 200000 AUD, Lifetime : 150000 Euros, Lifetime : 75000 GBP
Standard warranty
2 years repair or replace, 3 years repair or replace for European Union countries
Sustainable Offer Status
RoHS
Compliant
REACH
REACH: Contains SVHCs
PEP
Available in Documentation tab
EOLI
Available in Documentation tab
Additional information
| Weight | 13.2 lbs |
|---|---|
| Dimensions | 488 × 238 × 387 in |
