Description

Technical Specifications

• Processor: High performance embedded microprocessor
• Operating System: Embedded LINUX
• User Interface: GUI
• Video Input: 4 channel, BNC
• Video Output: 1 HDMI, 1 VGA
• Video Standard: Analog: 4Ch. @1080N , 4Ch. @720P , 4Ch@960H / Hybird: 2Ch. @720P(analog) + 2Ch. @720P(ip) / IP: 8Ch. @1080P;12Ch. @960P;8Ch. @720P; 4Ch. @1080P; 4Ch. @720P; 1Ch. @1080P
• Compression:  H.264 / G.711a
• Video Resolution: 1920×1080, 1280×1024, 1280×720, 1024×768, 800×600
• Audio Input:  4 channel
• Audio Output: 1 channel
• Hard Dis: 1 SATA port, up to 8TB
• Smart Phone: iPhone, iPad, Android
• HDD Management: HDD Storage, Network Storage
• Recording Mode: Manual>Alarm>Motion detection>Timing
• Search Mode: Search by Time/Calendar/Event/Channel
• Playback: 4 Ch.
• Backup Mode: Network, USB, SATA
• Interface Ports: 2 USB 2.0, 1 RS485, 1 RJ45
• Ethernet: RJ45 10M/100M Adaptive Ethernet port
• Protocols: ONVIF Supports
• Power Supply: 12V/2A
• Power Consumption: <10W(Without HDD)
• Working Temp: 0 °C – + 55 °C, 10% -90% RH
• Dimension: 255 mm(L) x 236mm(W) x 44mm(H)
• Weight: 1 KG
