Description

Technical Specifications

• Image Sensor: 1/2.9″ 1.3 MP HQIS Pro Image Sensor
• Minimum Illumination: Color (0.1Lux), White and Black (0Lux IR LED On)
• Shutter Speed: PAL:1/50~1/100000s NTSC:1/30~1/10000S
• White Balance: Auto
• Lens: 3.6mm
• AGC Control: Auto
• S/N Ratio: >52dB (AGC OFF/BW OFF)
• Back Light Comp.: Auto
• Video Streaming: 1.3MP@25 fps
• Video Output: 1.0Vp-p75O
• ICR: Supports
• IR: IR Range of 20 Mtr.
• No. of IR LEDs: 24
• Operating Temperature: -10°C~+50°C
• Power Source: DC12V
• Power Consumption: 0.4W(2.5W after IR LED Powered on)
• Dimension: 99.85mm x 99.85mm x 69.80mm
• Weight: 0.15 kG.
