Description

Technical Specification

• Image Sensor: 1/2.7″ 2.4MP HQIS Pro Image Sensor
• Minimum Illumination: Color(0.1Lux), (0 Lux IR LED On)
• Shutter Speed: 1/50s(1/60s)-1/100,000s(Auto/Fixed)
• White Balance: Auto
• Lens: 3.6mm
• AGC Control: Auto
• S/N Ratio: ≥41dB
• Back Light Comp.: Auto / DWDR
• Resolution: 2.4MP @ 25fps
• Video Output: 1.0Vp-p Composite Output (75O / BNC), HD-AHD(1080P) HD-TVI(1080P) HD-CVI(1080P) CVBS , CVI Default setting
• Frame Rate: 30fps(60Hz) , 25fps(50Hz)
• ICR: support
• Gamma Correction: 0.45
• IR: IR Range of 20 Mtr.
• No. of IR LEDs: 12pcs
• Operating Temperature: -20°C~+55°C
• Humidity: 10% ~ 90% (humidity), =95% RH no dew
• Power Source: DC12V(+/-10%)
• Power Consumption: 0.4W(2.5W after IR LED Powered on)
• Weatherproof Standard: IP66
• Dimension: 154.6mm x 60.8mm x 91.1mm
• Weight: 0.28 KG
