Description

Technical Specifications

Image Sensor: 1/4″ 1 MP HQIS Pro Image Sensor

Minimum Illumination: Color(0.1Lux), (0 Lux IR LED On)

Shutter Speed: 1/50s(1/60s)-1/100,000s(Auto/Fixed)

White Balance: Auto

Lens: 3.6mm

AGC Control: Auto

S/N Ratio: ≥39dB

Back Light Comp.: Auto

Resolution: 720P

Video Output: 1.0Vp-p Composite Output (75O / BNC) , HD-AHD(720P) HD-TVI(720P) HD-CVI(720P) CVBS, CVI Default setting

Frame Rate: 30fps(60Hz) , 25fps(50Hz)

ICR: support

Gamma Correction: 0.45

IR: IR Range of 20 Mtr.

No. of IR LEDs: 12pcs

Operating Temperature: -20°C~ 55°C

Humidity: 10% ~ 90% , =95% RH no dew

Power Source: DC12V(+/-10%)

Power Consumption: 0.4W(2.5W after SMD LED Powered on)

Dimension: 159.27mm x 70mm x 76.25mm

Weight: 0.2 Kg.
